BUTYL ALU-PET TAPE (0,6 mm THICKNESS) [WHITE COLOR] (103)
https://www.atyt.es/shop/butyl-alu-pet-tape-0-6-mm-thickness-white-color-103-94 https://www.atyt.es/web/image/product.template/94/image_1920?unique=ae130b8Length: 10 m |
Thickness: 0.6 mm |
Support color: White |
Liner color: Grey |
Adhesive type: Butyl |
Packaging type: POF Shrinked |
Share:
BUTYL ALU-PET TAPE
Durable, Flexible and Waterproof Sealing Solution
The white 0.6 mm PET/ALU butyl tape is an advanced sealing and waterproofing solution for multiple industries. Its composition combines a laminated support of aluminum and polyester (PET) with a modified butyl rubber adhesive, offering superior adhesion and long-lasting performance under a wide range of environmental conditions.
COMPOSITION

Support upper part (A): Aluminium film of 25 µm
Support lower part (A): PET film of 23 µm
Adhesive (B): Elastomeric modified butyl rubber
Liner (C): PP film of 70 µm
KEY FEATUTRES

Immediate and long-lasting adhesion – No heat or special tools required.
Excellent weather resistance – Withstands UV, rain, wind, salt, and snow.
Chemical resistance: Tolerates diluted acids, alkalis, and saline solutions.
Dimensional stability – Will not shrink or deform over time.
Malleable and adaptable – Perfect for corners, curves, and uneven joints.
PROS AND CONS, WHY CHOOSE IT?
✅ Advantages
- Superior waterproofing
- Excellent adhesion on various surfaces
- Long-lasting performance in extreme conditions
- Easy to apply, no tools needed
- Suitable for indoor and outdoor use
⚠ Disadvantages
- Requires clean and dry surfaces for best adhesion
- Not suitable for areas under constant water pressure
- Primer recommended on porous surfaces
APPLICATIONS AND SECTORS

🔧 HVAC
- Air ducts and climate control systems
🏗 Construction
- Roofs, façades, windows, doors
🚗 Automotive and marine
- Caravan roofs, boat repairs
⚡ Solar energy
- Photovoltaic panel sealing
🎯 Target Audience
- Construction professionals
- Maintenance technicians
- DIY enthusiasts
- Industrial companies
CERTIFICATIONS
In the "Documents" tab you will find the certifications that our product has.
In case you need any other type of certification to apply the product in your field, please contact us.
Discover more
PRODUCT REVIEWS
The 0.6 mm white butyl PET/ALU tape is an essential tool for achieving effective and long-lasting seals in a wide range of applications. Its multilayer structure offers a reliable solution against leaks and moisture-related damage. While it requires some surface preparation and may not be suitable for every condition, its many advantages far outweigh the limitations. It is a smart investment for professionals and users looking for quality and efficiency in sealing and waterproofing projects.
RELATED PRODUCTS
STORAGE CONDITIONS
For better preservation of its properties, the product should be stored in its original packaging at a temperature between 20 and 30ºC, protected from direct sunlight and moisture. It is recommended to use the product within 24 months after receipt.
GENERAL WARRANTY CONDITIONS
ATyT recommends that the contact surfaces be clean of grease, oil, dust or any other non-stick substance.
The technical data contained in this product specification is intended to guide the end user and does not imply a legal guarantee regarding certain properties, due to the numerous influences that may occur during the handling and use of the product.
Before use, the consumer must evaluate the suitability of the product for its specific purpose and will assume all risk and responsibility in relation to such use.
ADHESIVE PROPERTIES | VALUES | METHOD |
---|---|---|
Total Thickness |
0.6 mm
|
ASTM D-3652
|
Watertightness
|
Approved |
IN 1928 + IN 1847
|
Tensile strength
|
≥ 2 N/mm2
|
IN 12311-2
|
Elongation at break |
≥ 10%
|
IN 12311-2
|
Adhesion to steel |
≥ 11 N/cm
|
ASTM D-3330
|
Impact resistance |
≥ 300 mm
|
IN 12691
|
Resistance to static loading |
≥ 10 kg
|
EN 12730-METHOD B
|
Tear resistance |
≥ 30 N
|
IN 12310-2
|
Joint strength |
≥ 240 N/cm
|
IN 12317-2
|
Loop Tack |
≥ 33 N
|
ASTM D-6195
|
Moisture resistance factor |
≥ 230.000 µm
|
IN 1931
|
Aplication temperature range
|
[+5ºC - +35ºC]
|
INTERNAL |
Service temperature range |
[-20ºC - +80ºC]
|
INTERNAL |

A: Outside diameter (mm)
B: Inner diameter (mm)
C: Width (mm)
D: Length (m)
A |
120 mm
|
|||
B |
76 mm
|
|||
C |
100,
150,
200,
250,
300 mm |
|||
D |
10 m
|
